AUDIO
Frequency Response: 20Hz to 22kHz ≤ ± 0.25dB
Maximum Input Before Clip: +18dBu
Maximum Output Level:+18dBu
Input Impedance: >20 kΩ
Output Impedance:50 Ω
Distortion (Analogue in to Dante Out):0.0013% THD+N @ 1kHz Reference to +18dBu output
Distortion (Dante in to Analogue Out):0.0026% THD+N @ 1kHz Reference to +18dBu output
Noise (Analogue In & Out @ 0dBu): -92dBu (Residual)
Dynamic Range: 108dBs
Crosstalk (0dBu input to output 1kHz tone):-135dBu
Output Type:Electronically balanced (can be wired Unbalanced) on Neutrik 3 pin XLR socket
Input Type:Electronically balanced (can be wired unbalanced) on Neutrik 3 pin XLR plug
Digital Full Scale:+18dBu = 0dBFs
NETWORK AUDIO
Compatible Audio Networks:Dante® uncompressed, low latency audio. AES67
Connector: Neutrik EtherCON (also mates with standard RJ45s)
Dante Network Sample Rate: 4 Audio Channels: 44.1k, 48k, 2 Audio Channels: 88.2k, 96k
Resolution: Up to 24 Bit
AES67 Network Sample Rate: 48k
Ethernet Interface: 100BASE-TX
Chipset: Ultimo UXT-01-004 (Note: Audinate recommends no more than 10 Ultimo chipsets on one network UNLESS another Dante® device such as the Brooklyn is present)
POWER
DC Input:2.5mm Barrel, Centre +Ve, 9 - 15 Volts
Consumption: PoE: May be powered by PoE. Complies to: IEEE 802.3af-2003 Classification Class 0
Power On LED: Bright Blue
PHYSICAL
Size: 153 x 105 x 41mm (WxDxH)
Weight: 420g
Mechanics: All aluminium construction, anodized and laser etched
ENVIRONMENTAL
Operating Temperature: 0 to +50°C (32 to 122°F)
Storage Temperature: -20 to +70°C (-4 to 158°F)
Relative Humidity: 0 to 95% non-condensing
INCLUDED ITEMS
Handbook: Paper Copy (Download also available)
RJ45 Network Cable: 2 metre Cat5 RJ45 plug/ RJ45 plug cable
Rubber Feet: 4 x stick on rubber feet
